9106a

9106a; Philips; Eindhoven (ID = 864277) R-Player

9106a; Philips; Eindhoven (ID = 864278) R-Player

9106a; Philips; Eindhoven (ID = 864276) R-Player
9106a; Philips; Eindhoven (ID = 864272) R-Player 9106a; Philips; Eindhoven (ID = 864273) R-Player
9106a; Philips; Eindhoven (ID = 864275) R-Player 9106a; Philips; Eindhoven (ID = 864609) R-Player
Use red slider bar for more.
9106a; Philips; Eindhoven (ID = 864272) R-Player
Philips; Eindhoven: 9106a [R-Player] ID = 864272 933x497
Select picture or schematic to display from thumbnails on the right and click for download.
For model 9106a, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1969 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 7:
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: 9106a - Philips; Eindhoven tubes
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Notes Zweispur-Mono. Bandgeschwindigkeit: 9,5 cm/s;
Spulen-Ø: 15 cm; Übertragungsbereich: 80-12000 Hz.
Source of data -- Original-techn. papers.

Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
