A.C. Current Probe and Amplifier PM9355

A.C. Current Probe and Amplifier PM9355; Philips; Eindhoven (ID = 1643157) Equipment A.C. Current Probe and Amplifier PM9355; Philips; Eindhoven (ID = 1643158) Equipment
A.C. Current Probe and Amplifier PM9355; Philips; Eindhoven (ID = 1643159) Equipment
Use red slider bar for more.
A.C. Current Probe and Amplifier PM9355; Philips; Eindhoven (ID = 1643157) Equipment
Philips; Eindhoven: A.C. Current Probe and Amplifier PM9355 [Equipment] ID = 1643157 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model A.C. Current Probe and Amplifier PM9355, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1978 ?? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 9: BC548 BC549 BCY71 BCY71 BF173 BF324 BF324 BFY90 BFY90
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: A.C. Current Probe and Amplifier PM9355 - Philips; Eindhoven tubes
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 142 x 42 x 155 mm / 5.6 x 1.7 x 6.1 inch
Notes

Strommesszange mit Verstärker zum Anschluß an Oszilloskop mit Eingangswiderstand 50 Ω.
Über mitgelieferten Adapter auch an Oszilloskope mit 1 MΩ-Eingangswiderstand verwendbar.

Bandbreite ≤ 12 Hz ≥ 70 MHz (-3 dB) / 5 mA/DIV bis 1 A/DIV und ≤ 12Hz ≥ 45 MHz (-3 dB) / 1 mA/DIV und 2 mA/DIV.

Angegebenes Gewicht bezieht sich auf den Verstärker ohne Steckernetzteil und Zange!



Net weight (2.2 lb = 1 kg) 0.760 kg / 1 lb 10.8 oz (1.674 lb)

Model page created by Giovanni Cucuzzella. See "Data change" for further contributors.
