• Country
• Hong Kong

• Manufacturer / Brand
• Philips Hong Kong

• Year
• 1987 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 130910

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 220 / 4 × 1,5 & 2 × 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch

• Power out
• 0.5 W (unknown quality)

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: AE-2402/00 - Philips Hong Kong

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 220 x 120 x 40 mm / 8.7 x 4.7 x 1.6 inch

• Notes
• Philips AE-2402; récepteur PLL, avec horloge et réveil intégré.
  5 mémoires sur chaque gamme. 2 piles LR6 pour le computer, et 4 piles LR6 pour le récepteur même.

• Net weight (2.2 lb = 1 kg)
• 0.7 kg / 1 lb 8.7 oz (1.542 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Bernardo Diaz. See "Data change" for further contributors.

• Other Models

• Here you find 70 models, 69 with images and 27 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Philips Hong Kong
