AG4331 /00G /00L

AG4331 /00G /00L; Philips; Eindhoven (ID = 1549311) R-Player

AG4331 /00G /00L; Philips; Eindhoven (ID = 1549312) R-Player

AG4331 /00G /00L; Philips; Eindhoven (ID = 1549313) R-Player

AG4331 /00G /00L; Philips; Eindhoven (ID = 1549314) R-Player

AG4331 /00G /00L; Philips; Eindhoven (ID = 1549315) R-Player

AG4331 /00G /00L; Philips; Eindhoven (ID = 1549316) R-Player

AG4331 /00G /00L; Philips; Eindhoven (ID = 1549317) R-Player

AG4331 /00G /00L; Philips; Eindhoven (ID = 1549318) R-Player

AG4331 /00G /00L; Philips; Eindhoven (ID = 1549319) R-Player

AG4331 /00G /00L; Philips; Eindhoven (ID = 1549320) R-Player
Use red slider bar for more.
AG4331 /00G /00L; Philips; Eindhoven (ID = 1549311) R-Player
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1965 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 4: AC125 AC125 AC128 AC128
Main principle Audio-Amplification; 3 AF stage(s)
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: AG4331 /00G /00L - Philips; Eindhoven tubes
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 320 x 140 x 260 mm / 12.6 x 5.5 x 10.2 inch
Notes
  • Record player with 2 speed: 33/45 rpm.
  • 2 cabinet colors:  /00G = grey, /00L = red.
  • Pick-Up heads: AG3306 or AG3310 or AG3224 or AG3228.
  • Loudspeaker type AD3721.
Mentioned in -- Original-techn. papers.
