Alarm Clock Radio AJ3540 /05 /12 /37 /79 /96

Philips 飞利浦; China

  • Year
  • 2006 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 330695

 Technical Specifications

  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / see remarks: 110 to 240 & backup battery 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2 inch = 5.1 cm
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Alarm Clock Radio AJ3540 /05 /12 /37 /79 /96 - Philips 飞利浦; China
  • Shape
  • Tablemodel with Clock ((Alarm-) Clock Radio).
  • Dimensions (WHD)
  • 8.5 x 4 x 3 inch / 216 x 102 x 76 mm
  • Notes
  • Dual alarm clock.

    Power requirements:

    • /05 = 230 - 240 V, 50 Hz
    • /12 = 230 - 240 V, 50 Hz
    • /37 = 120 V, 60 Hz
    • /75 = 230 - 240 V, 50 Hz
    • /96 = 110 - 127 V, 60 Hz
  • Net weight (2.2 lb = 1 kg)
  • 0.5 kg / 1 lb 1.6 oz (1.101 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (User manual)
  • Author
  • Model page created by Serioja Tatu. See "Data change" for further contributors.
