AJ3600 /00

AJ3600 /00; Philips Radios - (ID = 942612) Radio AJ3600 /00; Philips Radios - (ID = 942611) Radio
AJ3600 /00; Philips Radios - (ID = 942613) Radio AJ3600 /00; Philips Radios - (ID = 942614) Radio
AJ3600 /00; Philips Radios - (ID = 942615) Radio AJ3600 /00; Philips Radios - (ID = 942617) Radio
AJ3600 /00; Philips Radios - (ID = 1899632) Radio AJ3600 /00; Philips Radios - (ID = 1899635) Radio
AJ3600 /00; Philips Radios - (ID = 1899636) Radio AJ3600 /00; Philips Radios - (ID = 1899639) Radio
Use red slider bar for more.
AJ3600 /00; Philips Radios - (ID = 942612) Radio
Philips Radios -: AJ3600 /00 [Radio] ID = 942612 933x398
Select picture or schematic to display from thumbnails on the right and click for download.
For model AJ3600 /00, Philips Radios - Deutschland

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1985 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) TDA1220 TBA820 TMS3459
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: AJ3600 /00 - Philips Radios - Deutschland
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Clock ((Alarm-) Clock Radio).
Dimensions (WHD) 255 x 70 x 150 mm / 10 x 2.8 x 5.9 inch
Notes ICs: IC1=TDA1220B, IC2=TBA820, IC3=TMS3459BNL
Backup battery for clock: 9 V.
Net weight (2.2 lb = 1 kg) 1 kg / 2 lb 3.2 oz (2.203 lb)

Model page created by Julián Muñoz Lorenzo. See "Data change" for further contributors.
