AM-FM Stereo Tuner 102 90AH102 /00 /12 /15

AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072610) Radio

AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072611) Radio

AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072612) Radio

AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072613) Radio

AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072614) Radio

AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072615) Radio

AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072625) Radio
AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072187) Radio AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072201) Radio
AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072202) Radio AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072203) Radio
AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072204) Radio
Use red slider bar for more.
AM-FM Stereo Tuner 102 90AH102 /00 /12 /15; Philips Hong Kong (ID = 2072187) Radio
Philips Hong Kong: AM-FM Stereo Tuner 102 90AH102 /00 /12 /15 [Radio] ID = 2072187 1400x787
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM-FM Stereo Tuner 102 90AH102 /00 /12 /15, Philips Hong Kong

Country:  Hong Kong
Manufacturer / Brand:  Philips Hong Kong
Year: 1980 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 14: BF324 BF495 BF494 BC548 BC558 MJE521 BA216 FV1043 1N4001 TDA4420 LM1800
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 110-127; 220-240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: AM-FM Stereo Tuner 102 90AH102 /00 /12 /15 - Philips Hong Kong
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 450 x 80 x 380 mm / 17.7 x 3.1 x 15 inch
Notes

Wavebands:

  • LW 150 - 255 kHz
  • MW 520 - 1605 kHz
  • FM 87.5 - 108 MHz

Switches: AFC, SNC, Mono/Stereo.

See also Philips 22AH102 /12 which shares the service manual.
Semi-conductors listed once per type.

Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Juan Bautista Ruiz Pérez. See "Data change" for further contributors.
