Amplifier Unit 30W 983A

Amplifier Unit 30W 983A; Philips Australia (ID = 2400091) Ampl/Mixer Amplifier Unit 30W 983A; Philips Australia (ID = 2400092) Ampl/Mixer
Amplifier Unit 30W 983A; Philips Australia (ID = 2400093) Ampl/Mixer Amplifier Unit 30W 983A; Philips Australia (ID = 2403891) Ampl/Mixer
Amplifier Unit 30W 983A; Philips Australia (ID = 2400094) Ampl/Mixer Amplifier Unit 30W 983A; Philips Australia (ID = 2403888) Ampl/Mixer
Amplifier Unit 30W 983A; Philips Australia (ID = 2403889) Ampl/Mixer Amplifier Unit 30W 983A; Philips Australia (ID = 2403890) Ampl/Mixer
Use red slider bar for more.
Amplifier Unit 30W 983A; Philips Australia (ID = 2400091) Ampl/Mixer
Philips Australia: Amplifier Unit 30W 983A [Ampl/Mixer] ID = 2400091 1400x520
Select picture or schematic to display from thumbnails on the right and click for download.
For model Amplifier Unit 30W 983A, Philips Australia:
Philips 983A Front

Country:  Australia
Manufacturer / Brand:  Philips Australia
Year: 1953 Category: Audio Amplifier or -mixer
Valves / Tubes 4: 12AX7 EL34 EL34 GZ32
Main principle Audio-Amplification
Details
Power type and voltage 220, 240, 260 Volt
Loudspeaker - This model requires external speaker(s).
Power out 30 W (max.)
from Radiomuseum.org Model: Amplifier Unit 30W 983A - Philips Australia
Material Metal case
Shape Rack
Dimensions (WHD) 480 x 175 x 200 mm / 18.9 x 6.9 x 7.9 inch
Notes

This unit is a slave amplifier and designed to be use with an external mixer etc.

This Unit was designed to be configured to suit its purpose and could be mounted in a cabinet with other units or used with a rack mount kit.

Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)

Model page created by Joshua Boxer. See "Data change" for further contributors.
