For model Anódpótló 372, Philips; Budapest:
Thanks for Mr.Perneky Sándor, Verőce Rádiómúzeum ( radiomuzeum.hu ).

Country:  Hungary
Manufacturer / Brand:  Philips; Budapest
Year: 1926–1930 Category: Power supply/conditioner or battery or charger
Valves / Tubes 1: 373
Wave bands - without
Details Power: B-Battery Eliminator
Power type and voltage Alternating Current supply (AC) / 100; 110; 150; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Anódpótló 372 - Philips; Budapest
Material Metal case, TUBES VISIBLE
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 120 x 150 x 200 mm / 4.7 x 5.9 x 7.9 inch
Notes

30 - 200 V / 30 mA.

Height without valve.

Price in first year of sale 120.00 Pengő
Mentioned in Magyar Rádió Újság 1926.
Literature/Schematics (1) Rádió Szaklap 1928.
Literature/Schematics (2) Reich Miklós katalógus, Budapest, 1930.
Literature/Schematics (3) Magyar Rádió Újság 1927.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
