For model Automatic Digital VAΩ Meter PM2524, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1978 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Line / Batteries (any type) / 98 - 238 / 5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Automatic Digital VAΩ Meter PM2524 - Philips; Eindhoven tubes
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 235 x 95 x 280 mm / 9.3 x 3.7 x 11 inch
Notes Philips Automatic Digital VAΩ Meter PM2524
;Messbereichswahl automatisch oder manuell,
Anzeigeumfang 4 1/2 Digits
Messbereiche:
Gleichspannung: 200 mV...2000 V in 5 Bereichen; beste Auflösung 10 µV
Wechselspannung: 2 V...2000 V in 4 Bereichen; beste Auflösung 100 µV; 40 Hz...30 kHz
Gleich- und Wechselstrom: 2000 mA; beste Auflösung 100 µA
Widerstand: 2 kΩ...20 MΩ in 5 Bereichen; beste Auflösung 100 mΩ
Temperaturmessungen mit optionalem Messfühler PM 9248 möglich.

Seleccion automatica de escala en todas las medidas, 4 digitos y medio.
Rangos de medida:
DC 10 µV a 1000 V, DCA 100 µA a 2 A,
AC 100 µV a 600 V, ACA 100 µA a 2A,
Ohm 0.1 Ohm a 20 MOhm,
Temp -60º a +200º (sonda opcional)
Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
Source of data - - Manufacturers Literature
Literature/Schematics (1) -- Original-techn. papers.
