B1X65U /00 /01

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1956–1966

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 29615

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• UCH81 UBF80 UCL82 UY42

• Main principle
• Superheterodyne (common); ZF/IF 452 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• AC/DC-set / 110-220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• from Radiomuseum.org
• Model: B1X65U /00 /01 - Philips; Eindhoven tubes

• Dimensions (WHD)
• 242 x 158 x 131 mm / 9.5 x 6.2 x 5.2 inch

• Notes
• Ausf. 00 = 220V, Ausf. 01 = 110-127V

• Author
• Model page created by Iven Müller. See "Data change" for further contributors.
