B2X02A /19F /19G /19W /71R; Philips; Eindhoven (ID = 98283) Radio
Philips; Eindhoven: B2X02A /19F /19G /19W /71R [Radio] ID = 98283 933x553
Select picture or schematic to display from thumbnails on the right and click for download.
For model B2X02A /19F /19G /19W /71R, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 UABC80 UL84 UY85
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out
from Radiomuseum.org Model: B2X02A /19F /19G /19W /71R - Philips; Eindhoven tubes
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 310 x 167 x 176 mm / 12.2 x 6.6 x 6.9 inch
Notes Spartransformator
Net weight (2.2 lb = 1 kg) 3.6 kg / 7 lb 14.9 oz (7.93 lb)

Model page created by Iven Müller. See "Data change" for further contributors.



All listed radios etc. from Philips; Eindhoven (tubes international!); Miniwatt
Here you find 4981 models, 4169 with images and 3324 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Philips; Eindhoven: B2X02A /19F /19G /19W /71R
Threads: 1 | Posts: 1
Hits: 1473     Replies: 0
philips: B2X02A;
Georges Werts
18.Oct.12
  1

Mon modèle est un B2X02A/71 et non 71R ! Je suppose que c'est une dernière version car il

est équipé de 5 Tubes ECC85, ECH81, EF89, EABC80, et EL95.

Le redresseur est un pont semiconducteur Siemens type B250C75.

Cordialement

G.W.


Philips; Eindhoven: B2X02A /19F /19G /19W /71R
