For model B3G97U, Philips Electrical, Lamps, Industrial - Miniwatt; London

Country:  Great Britain (UK)
Manufacturer / Brand:  Philips Electrical, Lamps, Industrial - Miniwatt; London
Year: 1960 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: UF80 UF80 UCH81 UF89 UABC80 UL84 UY85
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz; 2 AF stage(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage AC/DC-set / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out
from Radiomuseum.org Model: B3G97U - Philips Electrical, Lamps,
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 340 x 235 x 180 mm / 13.4 x 9.3 x 7.1 inch
Notes Similar chassis to model B3G75U.
Net weight (2.2 lb = 1 kg) 3.8 kg / 8 lb 5.9 oz (8.37 lb)
Source of data Radio And Television Servicing books (R&TVS)

Model page created by Keith Staines. See "Data change" for further contributors.
