B4X66U; Philips; Eindhoven (ID = 948448) Radio
Philips; Eindhoven: B4X66U [Radio] ID = 948448 933x721
Select picture or schematic to display from thumbnails on the right and click for download.
For model B4X66U, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1956/1957 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCH81 UF89 UBC81 UL84 DM71 UY42
Main principle Superheterodyne (common); ZF/IF 452 kHz
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage AC/DC-set / 110-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: B4X66U - Philips; Eindhoven tubes
Material Bakelite case
Dimensions (WHD) 370 x 275 x 196 mm / 14.6 x 10.8 x 7.7 inch
Notes 3 KW-Bereiche
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Iven Müller. See "Data change" for further contributors.
