• Year
  • 1993 ??
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 278412

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 14.4 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 58 W (max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Cassette car radio 22DC722 /00 - Philips; Eindhoven tubes
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 180 x 51 x 150 mm / 7.1 x 2 x 5.9 inch
  • Notes
  • Features CD changer control capability

    Cassette mechanism SCA-4.4

    Detachable front panel

    Can drive 4 loudspeakers, 4 ohm each, with 14,5W at 10% THD.
    The service manual also mentions 4 x 30W.

    Similar to 22DC712 /00 which has different amplifier stage (2xTDA7374 in 22DC722, 1xTDA7374 in 22DC712)

  • Mentioned in
  • -- Original-techn. papers.
  Philips 22DC722 Service Manual courtesy of member Peter Löytynoja 3387 KB
  • Documents regarding this model
  • Author
  • Model page created by Peter Löytynoja. See "Data change" for further contributors.
