CD Stereo Digital Midi System FCD195 /10 /30 /31 /32 /35 /38 /40

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1985 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 327708

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Other Combination - see Notes

• Power type and voltage
• Alternating Current supply (AC) / 120; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 20 W (undistorted)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: CD Stereo Digital Midi System FCD195 /10 /30 /31 /32 /35 /38 /40 - Philips; Eindhoven tubes

• Shape
• Book-shelf unit.

• Notes

• Philips CD Stereo Digital Midi System FCD195

  • Record player type HP7D277
  • Integrated stereo amplifier
  • Double cassette deck type RX-4
  • CD Player

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
