Converter Unit DC to AC Square 28.891.460

Converter Unit DC to AC Square 28.891.460; Philips Electrical, (ID = 1314557) Power-S

Converter Unit DC to AC Square 28.891.460; Philips Electrical, (ID = 1314555) Power-S

Converter Unit DC to AC Square 28.891.460; Philips Electrical, (ID = 1314556) Power-S

Converter Unit DC to AC Square 28.891.460; Philips Electrical, (ID = 1314558) Power-S
Converter Unit DC to AC Square 28.891.460; Philips Electrical, (ID = 2121025) Power-S Converter Unit DC to AC Square 28.891.460; Philips Electrical, (ID = 2121026) Power-S
Use red slider bar for more.
Converter Unit DC to AC Square 28.891.460; Philips Electrical, (ID = 2121025) Power-S
Philips Electrical,: Converter Unit DC to AC Square 28.891.460 [Power-S] ID = 2121025 850x753
Select picture or schematic to display from thumbnails on the right and click for download.
For model Converter Unit DC to AC Square 28.891.460, Philips Electrical, Lamps, Industrial - Miniwatt; London:
Converter 28.891.460, entnommen aus einem Siera S4U

Country:  Great Britain (UK)
Manufacturer / Brand:  Philips Electrical, Lamps, Industrial - Miniwatt; London
Year: 1936 Category: Power supply/conditioner or battery or charger
Wave bands - without
Details
Power type and voltage Direct Current supply (DC) / 200-250 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Converter Unit DC to AC Square 28.891.460 - Philips Electrical, Lamps,
Shape Chassis only or for «building in»
Notes The DC to AC mains vibratory converter unit used in the Philips 745U, 790U, 791U, 792U, 794U, 795U and 797U models and the Mullard MUS3, MUS4 and MUS5 models.
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (594)

Model page created by Howard Craven. See "Data change" for further contributors.
