Data Cassette Recorder D6625-30P

Data Cassette Recorder D6625-30P; Philips Electronics (ID = 2273601) R-Player Data Cassette Recorder D6625-30P; Philips Electronics (ID = 2273600) R-Player
Data Cassette Recorder D6625-30P; Philips Electronics (ID = 2273603) R-Player Data Cassette Recorder D6625-30P; Philips Electronics (ID = 2273602) R-Player
Data Cassette Recorder D6625-30P; Philips Electronics (ID = 2274674) R-Player Data Cassette Recorder D6625-30P; Philips Electronics (ID = 1360744) R-Player
Data Cassette Recorder D6625-30P; Philips Electronics (ID = 1360745) R-Player Data Cassette Recorder D6625-30P; Philips Electronics (ID = 1360746) R-Player
Data Cassette Recorder D6625-30P; Philips Electronics (ID = 1360747) R-Player Data Cassette Recorder D6625-30P; Philips Electronics (ID = 1360748) R-Player
Use red slider bar for more.
Data Cassette Recorder D6625-30P; Philips Electronics (ID = 2273601) R-Player
Philips Electronics: Data Cassette Recorder D6625-30P [R-Player] ID = 2273601 1400x1311
Select picture or schematic to display from thumbnails on the right and click for download.
For model Data Cassette Recorder D6625-30P, Philips Electronics Japan, Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Philips Electronics Japan, Ltd.; Tokyo
Year: 1985 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 3: 2SC945 2SD467 2SC2785 µPC1350 LA2010 µPC1470
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Batteries / addl. power jack / AA: 4 x 1,5 / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.7 cm = 2.2 inch
Power out 0.6 W (max.)
from Radiomuseum.org Model: Data Cassette Recorder D6625-30P - Philips Electronics Japan, Ltd
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 115 x 35 x 195 mm / 4.5 x 1.4 x 7.7 inch
Notes

The Philips Data Recorder D6625-30P can be used either for sound recording (NOR) or for computer data recording (DATA).

Built-in electret condenser microphone.
Switch Phase Rev./Nor.

Made in Japan.

Net weight (2.2 lb = 1 kg) 0.550 kg / 1 lb 3.4 oz (1.211 lb)
Mentioned in -- Original-techn. papers.

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from Philips Electronics Japan, Ltd.; Tokyo
Here you find 17 models, 17 with images and 6 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Philips Electronics: Data Cassette Recorder D6625-30P
Threads: 1 | Posts: 4
Hits: 380     Replies: 3
philipsjap: D6625/60P
Hans Smit
26.Apr.20
  1

I have a D6625/60P.

What is the difference?

 "Made in Singapore only"?

Hans

Mark Hippenstiel
29.Apr.20
  2

Hello Hans,

There is currently no service manual for other versions than -30P to be found. Even though generally we try to group Philips models together, a new model should be created in the case of version -60P since it has a different country of manufacture.

From the home page, you can select "Create new model" - or "Modell anlegen" if you use the German interface - and then fill in the form with the necessary data.

You can also upload your images directly to the new model suggestion, they will show up in your collection later on.

If you need additional help, feel free to contact me directly.
Ik spreek ook nederlands als het dat wat makelijker maakt.

Thanks and kind regards
Mark

Peter Lang
01.May.20
  3

Hallo,

ich suche zum Modell D6625-30P die Bedienungsanleitung! Kann mir von Euch jemand sagen,

was die Funktionen bedeuten: Phase: REV; DATA: On - Off Monitor.

On Stellung NOR funktioniert der Recoreder bei Audio-/Daten-Aufnahme und Wiedergabe einwandfrei.

Über weine Antwort würde ich mich sehr freuen und bedanke mich schon im Voraus.

Viele Grüße



Peter Lang
01.May.20
  4

Verzeihung die Tippfehler, es sollte heißen: In Stellung....

Über eine Antwort.....


Philips Electronics: Data Cassette Recorder D6625-30P
End of forum contributions about this model
