Digital Multimeter PM2422 /A2 /A5

Digital Multimeter PM2422 /A2 /A5; Philips; Eindhoven (ID = 1450335) Equipment Digital Multimeter PM2422 /A2 /A5; Philips; Eindhoven (ID = 1450336) Equipment
Digital Multimeter PM2422 /A2 /A5; Philips; Eindhoven (ID = 1450338) Equipment Digital Multimeter PM2422 /A2 /A5; Philips; Eindhoven (ID = 1450339) Equipment
Digital Multimeter PM2422 /A2 /A5; Philips; Eindhoven (ID = 1450341) Equipment Digital Multimeter PM2422 /A2 /A5; Philips; Eindhoven (ID = 1450343) Equipment
Digital Multimeter PM2422 /A2 /A5; Philips; Eindhoven (ID = 1450344) Equipment Digital Multimeter PM2422 /A2 /A5; Philips; Eindhoven (ID = 1450345) Equipment
Digital Multimeter PM2422 /A2 /A5; Philips; Eindhoven (ID = 2299088) Equipment Digital Multimeter PM2422 /A2 /A5; Philips; Eindhoven (ID = 2299091) Equipment
Use red slider bar for more.
Digital Multimeter PM2422 /A2 /A5; Philips; Eindhoven (ID = 1450335) Equipment
Philips; Eindhoven: Digital Multimeter PM2422 /A2 /A5 [Equipment] ID = 1450335 920x722
Select picture or schematic to display from thumbnails on the right and click for download.
For model Digital Multimeter PM2422 /A2 /A5, Philips; Eindhoven (tubes international!); Miniwatt:
PM 2422/A2
Thanks for Mr.Portaskepu, Hungary, Budapest and Első Zalai Rádiómúzeum Alapítvány, First Zala County Radio Museum Foundation.

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1975 ?? Category: Service- or Lab Equipment
Valves / Tubes 3: ZM1005 ZM1005 ZM1005
Semiconductors (the count is only for transistors) Semiconductors present.
schematic requested
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Digital Multimeter PM2422 /A2 /A5 - Philips; Eindhoven tubes
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 230 x 140 x 295 mm / 9.1 x 5.5 x 11.6 inch
Notes 5 Bereiche Gleich- und Wechselspannungen: von 200mV - 1000V (Wechselspannungen 600V); 5 Bereiche Gleich- und Wechselströme: von 200µA - 2A; 6 Bereiche Widerstandsmessungen: 0-20MΩ; Alle Messbereiche mit Drehknopfschalter, AC-DC Umschaltung mit Drucktasten;
Collectors' prices

Model page created by Hugo Sneyers. See "Data change" for further contributors.
