Digitizing Oscilloscope 2 GHz PM 3340 /40 /80

Philips; Eindhoven (tubes international!); Miniwatt

Data
Forum
Pictures
Collections

  • Year
  • 1988 ?
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 299622

 Technical Specifications

  • Number of Tubes
  • 1
  • Valves / Tubes
  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 50-400 Hz, 100-240 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Digitizing Oscilloscope 2 GHz PM 3340 /40 /80 - Philips; Eindhoven tubes
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 465 x 250 x 570 mm / 18.3 x 9.8 x 22.4 inch
  • Notes

  • Philips PM 3340 is a single or dual channel digitizing (sampling) oscilloscope with a bandwidth of DC to 2 GHz (-3dB).

    Versions:

    • /40 table model (given dimensions)
    • /80 19 inch rackmount version
  • Net weight (2.2 lb = 1 kg)
  • 18.7 kg / 41 lb 3 oz (41.189 lb)
  • Mentioned in
  • - - Manufacturers Literature
  • Author
  • Model page created by Bernhard Nagel. See "Data change" for further contributors.
