EL3500 /05 /06 /65 /66
Philips Radios - Deutschland
- Country
- Germany
- Manufacturer / Brand
- Philips Radios - Deutschland
- Year
- 1956
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 242063
-
- Brand: Deutsche Philips-Ges.
Click on the schematic thumbnail to request the schematic as a free document.
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: EL3500 /05 /06 /65 /66 - Philips Radios - Deutschland
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 620 x 255 x 440 mm / 24.4 x 10 x 17.3 inch
- Notes
-
Professionelles Tonbandgerät für den Betrieb in Tonstudios.
Umschreibung der Typen-Nummern:
EL 3500/05 Tonbandlaufwerk umschaltbar auf 76 und 38 cm/s Bandgeschwindigkeit 220V/50Hz.
EL 3500/06 Tonbandlaufwerk umschaltbar auf 38 und 19 cm/s Bandgeschwindigkeit 220V/50Hz.
EL 3500/65 Tonbandlaufwerk umschaltbar auf 76 und 38 cm/s Bandgeschwindigkeit 220V/60Hz.
EL 3500/66 Tonbandlaufwerk umschaltbar auf 38 und 19 cm/s Bandgeschwindigkeit 220V/60Hz.
- Net weight (2.2 lb = 1 kg)
- 44 kg / 96 lb 14.7 oz (96.916 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
