• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1960 ??

• Category
• Microphone or Pick-up element

• Radiomuseum.org ID
• 96899

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• - For headphones or amp.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: EL3757 /00 /03 - Philips; Eindhoven tubes

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 52 x 117 x 52 mm / 2 x 4.6 x 2 inch

• Notes

• Philips EL 3757 Microphone for ELA Amplifiers

  Versions:

  • EL 3757 /00 Low ohmic dynamic stereo microphone for the recorder EL 3547
  • EL 3757 /03 As /00, however, 2nd brand versión and neutral.

  Tisch-Stereomikrofon, 2 Kapseln in Zylinder auf 3 Beinen aus Metall mit Gummifuss zum Stecken, Abmessungen nur Mikrofonkörper ohne Dreibein - mit Dreibein 16 cm hoch, mit Kabel und 5pol-DIN-Stecker.

• Literature/Schematics (1)
• -- Original-techn. papers.
