Five Band Portable Radio Receiver D2615 /40
Philips Hong Kong
- Country
- Hong Kong
- Manufacturer / Brand
- Philips Hong Kong
- Year
- 1985 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 363805
Ebay-au_205585461624
Ebay-au_205585461624
Ebay-au_205585461624
- Number of Transistors
- 4
- Main principle
- Superheterodyne (common); ZF/IF 468/10700 kHz
- Wave bands
- Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 50 Hz, 240 / D: 4 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 0.7 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Five Band Portable Radio Receiver D2615 /40 - Philips Hong Kong
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
-
For Australia ( /40)
Frequency range:
FM 87.5 - 108 MHz
MW 526.5 - 1606 kHz
LW 150 - 260 kHz
SW1 2.3 - 7.3 MHz
SW2 9.5 - 26 MHz
- Literature/Schematics (1)
- -- Original-techn. papers. (Service Manual, 4822 725 20803)
- Author
- Model page created by Martin Kent. See "Data change" for further contributors.
