• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1976–1978

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 124977

• • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• - For headphones or amp.

• from Radiomuseum.org
• Model: GA312 Electronic - Philips Radios - Deutschland

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 390 x 140 x 330 mm / 15.4 x 5.5 x 13 inch

• Notes
• HiFi-Stereo-Plattenspieler mit 33/45 UpM. Elektronisch tachogeregelter Gleichstrommotor mit Riemenantrieb; Drehzahlfeinregulierung und Skatingkompensation.

• Net weight (2.2 lb = 1 kg)
• 5.9 kg / 12 lb 15.9 oz (12.996 lb)

• Source of data
• Handbuch VDRG 1977/1978

• Mentioned in
• Handbuch VDRG 1976/1977

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
