Gleichspannungsstabilisator / Netzgerät (regelbar) PE-4800
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1959
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 183197
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 0
- Valves / Tubes
- 85A2
- Number of Transistors
- 4
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110-245 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Gleichspannungsstabilisator / Netzgerät PE-4800 - Philips; Eindhoven tubes
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 250 x 185 x 200 mm / 9.8 x 7.3 x 7.9 inch
- Notes
- Regelbares Gleichspannungsnetzgerät mit Analoganzeige. Ausgangsspannung 0 bis 20V. Max. Ausgangsstrom 300mA. Frontseitig Sicherungen für Primär- (AC) und Sekundärkreis (DC).
- Net weight (2.2 lb = 1 kg)
- 4.6 kg / 10 lb 2.1 oz (10.132 lb)
- Source of data
- - - Data from my own collection
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Thomas Jennen. See "Data change" for further contributors.
