Baby Grand 2020

Baby Grand 2020; Philips Electrical, (ID = 1504179) Speaker-P Baby Grand 2020; Philips Electrical, (ID = 1504181) Speaker-P
Use red slider bar for more.
Baby Grand 2020; Philips Electrical, (ID = 1504179) Speaker-P
Philips Electrical,: Baby Grand 2020 [Speaker-P] ID = 1504179 668x641
Select picture or schematic to display from thumbnails on the right and click for download.
For model Baby Grand 2020, Philips Electrical, Lamps, Industrial - Miniwatt; London

Country:  Great Britain (UK)
Manufacturer / Brand:  Philips Electrical, Lamps, Industrial - Miniwatt; London
Year: 1928 Category: Loudspeaker, headphone or earphone
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker Magnetic loudspeaker (reed) generic.
Power out
from Radiomuseum.org Model: Baby Grand 2020 - Philips Electrical, Lamps,
Material Bakelite case
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 335 x 330 x 110 mm / 13.2 x 13 x 4.3 inch
Notes
High impedance loudspeaker
Seven-sided black Bakelite rim with red spots on the corners and a purple-red coloured paper cone.
A tone control switch is situated at the back of the speaker.
It was the cheapest speaker that Philips made in that period.
The loudspeaker can be placed upright, using a metal bracket or mounted on a wall, or ceiling.

Model page created by John Koster. See "Data change" for further contributors.
