All Transistor Four Band L2W54T

Philips; Eindhoven (tubes international!); Miniwatt

  • Year
  • 1964 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 85771

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 10
  • Main principle
  • Superheterodyne (common); ZF/IF 452/10700 kHz
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Dry Batteries / 4 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
  • Power out
  • 0.38 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: All Transistor Four Band L2W54T - Philips; Eindhoven tubes
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 234 x 127 x 42 mm / 9.2 x 5 x 1.7 inch
  • Price in first year of sale
  • 3,650.00 BFr
  • Mentioned in
  • -- Original-techn. papers. (Philips Comercial Publishing "Série Juventude")
  • Author
  • Model page created by Mario Coelho. See "Data change" for further contributors.
