L5X22T /00 /01; Philips Radios - (ID = 406899) Radio
Philips Radios -: L5X22T /00 /01 [Radio] ID = 406899 900x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model L5X22T /00 /01, Philips Radios - Deutschland

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1962 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF114 AF115 AF116 AF116 AF116 OC75 OC75 OC74 OC74
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: L5X22T /00 /01 - Philips Radios - Deutschland
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 290 x 180 x 96 mm / 11.4 x 7.1 x 3.8 inch
Notes

Philips L5X22T /00, gefertigt in Wetzlar.

Siehe auch das niederländische Modell L5X22T /00 /01.

Mentioned in -- Original-techn. papers.

Model page created by Gidi Verheijen. See "Data change" for further contributors.
