For model LF449AB, Philips France; Paris

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1954/1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: DF96 DK92 DF91 DAF91 DM71 DL95
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Line / Storage batteries (perhaps also batteries) / AC 110;125; 220 / 2 x 67,5 & 2 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13.4 cm = 5.3 inch
Power out
from Radiomuseum.org Model: LF449AB - Philips France; Paris
Material Bakelite case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 260 x 245 x 135 mm / 10.2 x 9.6 x 5.3 inch
Notes

3 gammes d'ondes: GO 770 à 2000 m, OM 188 à 580 m, OC 19,2 à 51,7 m. Cadre Micro-capteur pour GO, multispires pour PO, monospire extérieur pour OC rabattable. Prises antenne-terre.

2 batteries de 67,5 V Leclanché 667G pour HT, 2 piles de 1,5 V Leclanché 120C pour filaments. Régulation HT par pont redresseur sur secteur. Possibilité de régénerer les piles HT sur 110 ou 220 V.

Coffret matière moulée, cadran et boutons en matière plastique.

Modèle équivalent au Radiola RA399AB (différences mineures).

Poids avec piles.

Net weight (2.2 lb = 1 kg) 4.5 kg / 9 lb 14.6 oz (9.912 lb)
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Le grand livre de la TSF (Doctsf Ref 2256)
Literature/Schematics (2) -- Original prospect or advert (Dépliant Série Super-Magnétique 1955)

Model page created by Vincent Baccialone. See "Data change" for further contributors.
