Lisette 12RL163

Lisette 12RL163; Philips Radios - (ID = 65079) Radio

Lisette 12RL163; Philips Radios - (ID = 65080) Radio

Lisette 12RL163; Philips Radios - (ID = 65082) Radio

Lisette 12RL163; Philips Radios - (ID = 65081) Radio

Lisette 12RL163; Philips Radios - (ID = 1923435) Radio

Lisette 12RL163; Philips Radios - (ID = 1990702) Radio

Lisette 12RL163; Philips Radios - (ID = 1990704) Radio

Lisette 12RL163; Philips Radios - (ID = 1990705) Radio

Lisette 12RL163; Philips Radios - (ID = 1990706) Radio
Lisette 12RL163; Philips Radios - (ID = 1304095) Radio Lisette 12RL163; Philips Radios - (ID = 65056) Radio
Lisette 12RL163; Philips Radios - (ID = 843929) Radio Lisette 12RL163; Philips Radios - (ID = 843930) Radio
Lisette 12RL163; Philips Radios - (ID = 843931) Radio
Use red slider bar for more.
Lisette 12RL163; Philips Radios - (ID = 1304095) Radio
Philips Radios -: Lisette 12RL163 [Radio] ID = 1304095 933x766
Select picture or schematic to display from thumbnails on the right and click for download.
For model Lisette 12RL163, Philips Radios - Deutschland

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1966–1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF124 AF125 AF126 AF126 AF126 AC127 AC127 AC128 AC128 AC128
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 5 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: Lisette 12RL163 - Philips Radios - Deutschland
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 200 x 100 x 50 mm / 7.9 x 3.9 x 2 inch
Notes

Netzbetrieb mit zusätzlichem Netzteil möglich.

Baugleich mit Grundig City-Boy 207.

Net weight (2.2 lb = 1 kg) 0.8 kg / 1 lb 12.2 oz (1.762 lb)
Collectors' prices
Source of data Handbuch VDRG 1967/1968 / Radiokatalog Band 1, Ernst Erb
