Micro Hifi-Fi System MCM398D /12

Micro Hifi-Fi System MCM398D /12; Philips 飞利浦; (ID = 2116822) Radio Micro Hifi-Fi System MCM398D /12; Philips 飞利浦; (ID = 2116823) Radio
Micro Hifi-Fi System MCM398D /12; Philips 飞利浦; (ID = 2116824) Radio Micro Hifi-Fi System MCM398D /12; Philips 飞利浦; (ID = 2116825) Radio
Micro Hifi-Fi System MCM398D /12; Philips 飞利浦; (ID = 2116826) Radio Micro Hifi-Fi System MCM398D /12; Philips 飞利浦; (ID = 2116827) Radio
Use red slider bar for more.
Micro Hifi-Fi System MCM398D /12; Philips 飞利浦; (ID = 2116822) Radio
Philips 飞利浦;: Micro Hifi-Fi System MCM398D /12 [Radio] ID = 2116822 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Micro Hifi-Fi System MCM398D /12, Philips 飞利浦; China

Country:  People's Republic of China
Manufacturer / Brand:  Philips 飞利浦; China
Year: 2007 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands FM Broadcast Band Only
Details Other Combination - see Notes
Power type and voltage Alternating Current supply (AC) / 50Hz, 220-230 Volt
Loudspeaker - This model requires external speaker(s).
Power out 100 W (unknown quality)
from Radiomuseum.org Model: Micro Hifi-Fi System MCM398D /12 - Philips 飞利浦; China
Material Modern plastics (no Bakelite or Catalin)
Shape Book-shelf unit.
Dimensions (WHD) 152 x 228 x 273 mm / 6 x 9 x 10.7 inch
Notes

Philips Micro Hi-Fi System mod. MCM398D/12 - potenza d'uscita musicale: 2 x 50 W RMS - 2 x 100 W PMPO - funzioni audio avanzate: 4 modalità di controllo - audio digitale - DBB (Dynamic Bass Boost) - casse acustiche a 2 vie: woofer 13 cm - tweeter piezoelettrico da 4" - griglie altoparlanti rimovibili - supporti di riproduzione: CD/CD-R/CD-RW/MP3/WMA-CD - modalità riproduzione dischi: 20 brani programmabili, ripeti brano/tutto/programma/ripetizione casuale - modalità USB diretta - avanzamento veloce,play/pause/previous/next/program play/ripetizione/avvia la riproduzione casuale/stop - sintonia digitale automatica RDS - impostazione orologio -stazioni preimpostate: 40 - auto store - ingresso Aux/Line in - presa per cuffia 3,5 mm - funzione sveglia - spegimento automatico - dispay LCD - controllo volume - eco power standby 1 watt - compatibile con:i-pod, mini i-pod,i-pod nano, i-pod shuffle, i-pod con dislay a colori - i-pod 5th generation - consumo 40 watt.

Made in China.

Net weight (2.2 lb = 1 kg) 8.7 kg / 19 lb 2.6 oz (19.163 lb)

Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
