Minauto III 11RN382 /02

Minauto III 11RN382 /02; Philips France; (ID = 2085097) Car Radio Minauto III 11RN382 /02; Philips France; (ID = 2085098) Car Radio
Minauto III 11RN382 /02; Philips France; (ID = 2072429) Car Radio Minauto III 11RN382 /02; Philips France; (ID = 2072430) Car Radio
Use red slider bar for more.
Minauto III 11RN382 /02; Philips France; (ID = 2085097) Car Radio
Philips France;: Minauto III 11RN382 /02 [Car Radio] ID = 2085097 1100x435
Select picture or schematic to display from thumbnails on the right and click for download.
For model Minauto III 11RN382 /02, Philips France; Paris:
ebay.fr #381948137349 seller basile590

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1969–1972 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 7: BF194 BF195 BF195 BC149 AC188 AD161 AD162 AA119 AA119 BA100
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 3 AF stage(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Minauto III 11RN382 /02 - Philips France; Paris
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 149 x 46 x 79 mm / 5.9 x 1.8 x 3.1 inch
Notes

2 gammes d'ondes PO et GO + 3 stations préréglées sur France-Inter, Europe 1 et Luxembourg.

Livré complet avec boîtier haut-parleur (elliptique de 10 x 14 cm, 4 ohms).

Les premières versions avaient un cadran différent (exécution /02 avec "M/L" et "382" sur la droite).

Équivalent au Radiola RA308T.

Net weight (2.2 lb = 1 kg) 0.550 kg / 1 lb 3.4 oz (1.211 lb)
