Normál 2

Normál 2; Philips; Budapest (ID = 2340441) Radio

Normál 2; Philips; Budapest (ID = 2340442) Radio

Normál 2; Philips; Budapest (ID = 2340443) Radio
Normál 2; Philips; Budapest (ID = 2340437) Radio Normál 2; Philips; Budapest (ID = 2340439) Radio
Normál 2; Philips; Budapest (ID = 2340440) Radio
Use red slider bar for more.
Normál 2; Philips; Budapest (ID = 2340437) Radio
Philips; Budapest: Normál 2 [Radio] ID = 2340437 1400x972
Select picture or schematic to display from thumbnails on the right and click for download.
For model Normál 2, Philips; Budapest:
Philips Csoda 3 kapcsolások. - Perneky Sándor - Rádiómúzeum Alapítvány, Verőce, Hungary, radiomuzeum.hu

Country:  Hungary
Manufacturer / Brand:  Philips; Budapest
Year: 1929 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 2: A415 B405
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 60-90 & 4 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Normál 2 - Philips; Budapest
Material Various materials
Shape Chassis only or for «building in»
Dimensions (WHD) 260 x 180 x 165 mm / 10.2 x 7.1 x 6.5 inch
Price in first year of sale 87.87 Pengő
Mentioned in Philips Csoda 3 kapcsolások

Model page created by Sándor Perneky. See "Data change" for further contributors.



All listed radios etc. from Philips; Budapest
Here you find 213 models, 209 with images and 115 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
