Universal-Messinstrument P817.00

Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 239361) Equipment

Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2405558) Equipment

Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2405559) Equipment
Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2228498) Equipment Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2228495) Equipment
Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2228500) Equipment Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2228507) Equipment
Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2228502) Equipment Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2228503) Equipment
Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2228504) Equipment Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2228505) Equipment
Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2228506) Equipment Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2228497) Equipment
Use red slider bar for more.
Universal-Messinstrument P817.00; Philips; Eindhoven (ID = 2228498) Equipment
Philips; Eindhoven: Universal-Messinstrument P817.00 [Equipment] ID = 2228498 1400x1116
Select picture or schematic to display from thumbnails on the right and click for download.
For model Universal-Messinstrument P817.00, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1958 Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage Dry Batteries / 1,5 & 22,5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Universal-Messinstrument P817.00 - Philips; Eindhoven tubes
Material Moulded (Bakelite or Plastics)
Dimensions (WHD) 180 x 130 x 80 mm / 7.1 x 5.1 x 3.1 inch
Notes

Universal-Messinstrument:

3, 12, 30, 120, 300, 1200 V (AC und DC, Genauigkeit 2%)

Gleich- und Wechselstrom: sechs Bereiche 120µA - 3A (bei Gleichstrom zusätzlicher Sonderbereich 30 µA Endausschlag).

Widerstand: 10 kΩ, 1MΩ und 10 MΩ

Gleichrichtung mit Germaniumdioden, daher auch für Tonfrequenzbereich geeignet, dB-Skala -10 dB bis +10 dB.

Innenwiderstand: DC 40.000 Ω/V, AC 1.666 Ω/V.

Der Originalpreis gilt für das Jahr 1965.

Net weight (2.2 lb = 1 kg) 1 kg / 2 lb 3.2 oz (2.203 lb)
Price in first year of sale 268.00 DM
Collectors' prices
Source of data -- Original prospect or advert

Model page created by Hugo Sneyers. See "Data change" for further contributors.
