For model Personal Media Composer PMC100, Philips 飞利浦; China

Country:  People's Republic of China
Manufacturer / Brand:  Philips 飞利浦; China
Year: 1986–1988 ? Category: Miscellaneous (Other, Various) - see notes
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Other Combination - see Notes
Power type and voltage Batteries / addl. power jack / R6: 6 x 1.5 / DC 9 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Personal Media Composer PMC100 - Philips 飞利浦; China
Material Plastics (no bakelite or catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 229 x 40 x 190 mm / 9 x 1.6 x 7.5 inch
Notes

PMC = Personal Media Composer. Musik-Synthesizer mit eingebautem Cassettenrecorder.
Die Datenbank des Synthesizers enthält 100 Melodiestimmen und Begleitstimmen. LCD-Anzeige.

  • Synthesizer-Chip: 6 Melodie- und 5 Rhytmus-Tracks
  • Microcontroller: 6803
  • ROM: 32 kbyte
  • RAM: 8 kbyte
  • Frequenzbereich: bis 16 kHz ± 3 dB
  • Signal-Rauschabstand 50 dB

Cassettenrecorder:

  • Frequenzbereich 60 Hz - 8 kHz +3 ... - 8 dB (Aufnahme/Wiedergabe)
  • THD+N 5%
  • Geräuschspannungsabstand 39 dB

Anschlüsse:

  • Ausgang 3.5 mm Stereo-Klinkenbuchse, 100 mW an 32 Ω
  • Mikrofoneingang 3.5 mm Stereo-Klinkenbuchse, -60 dB, 600 Ω
  • 9 V DC, Minuspol innen

Gewichtsangabe ohne Batterien.

Net weight (2.2 lb = 1 kg) 0.715 kg / 1 lb 9.2 oz (1.575 lb)
Mentioned in - - Manufacturers Literature (Service-Manual)

Model page created by Andreas Echtner. See "Data change" for further contributors.
