For model Jupiter 525A-14 output AL2, Philips akc. spol., Praha-Hloubetin

Country:  Czechoslovakia
Manufacturer / Brand:  Philips akc. spol., Praha-Hloubetin
Year: 1935/1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: AK1 AF2 AB1 E446 AL2 506
Main principle Superheterodyne (common); ZF/IF 115 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Jupiter 525A-14 [output AL2] - Philips akc. spol., Praha-
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 420 x 510 x 255 mm / 16.5 x 20.1 x 10 inch
External source of data Erb
Source of data Ceskoslovenske prijimace 1933-1945, Baudys 1947
