Philitina B1D43A; Philips Radios - (ID = 196898) Radio
Philips Radios -: Philitina B1D43A [Radio] ID = 196898 933x599
Select picture or schematic to display from thumbnails on the right and click for download.
For model Philitina B1D43A, Philips Radios - Deutschland

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1964/1965 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECC85 ECH81 EBF89 ECL86 EZ80
Semiconductors (the count is only for transistors) AA119 AA119
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Philitina B1D43A - Philips Radios - Deutschland
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 315 x 180 x 175 mm / 12.4 x 7.1 x 6.9 inch
Notes

Ovallautsprecher, Typ AD 2460Y/06, 5 Ω, 10 × 15 cm

(Sammel-Preisliste 64/65)

Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
Price in first year of sale 265.00 DM
Collectors' prices
External source of data Erb
Source of data Handbuch VDRG 1964/1965
Literature/Schematics (1) -- Schematic
