Pocket Radio AE-1595/00S

Pocket Radio AE-1595/00S; Philips 飞利浦; (ID = 761241) Radio Pocket Radio AE-1595/00S; Philips 飞利浦; (ID = 761236) Radio
Pocket Radio AE-1595/00S; Philips 飞利浦; (ID = 761237) Radio Pocket Radio AE-1595/00S; Philips 飞利浦; (ID = 761238) Radio
Pocket Radio AE-1595/00S; Philips 飞利浦; (ID = 761239) Radio Pocket Radio AE-1595/00S; Philips 飞利浦; (ID = 761240) Radio
Pocket Radio AE-1595/00S; Philips 飞利浦; (ID = 1863933) Radio Pocket Radio AE-1595/00S; Philips 飞利浦; (ID = 2138699) Radio
Pocket Radio AE-1595/00S; Philips 飞利浦; (ID = 2138700) Radio Pocket Radio AE-1595/00S; Philips 飞利浦; (ID = 2138701) Radio
Use red slider bar for more.
Pocket Radio AE-1595/00S; Philips 飞利浦; (ID = 761241) Radio
Philips 飞利浦;: Pocket Radio AE-1595/00S [Radio] ID = 761241 532x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Pocket Radio AE-1595/00S, Philips 飞利浦; China

Country:  People's Republic of China
Manufacturer / Brand:  Philips 飞利浦; China
Year: 1986 ?? Category: Broadcast Receiver - or past WW2 Tuner
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 3 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
Power out 0.1 W (unknown quality)
from Radiomuseum.org Model: Pocket Radio AE-1595/00S - Philips 飞利浦; China
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 72 x 125 x 33 mm / 2.8 x 4.9 x 1.3 inch
Notes Frequenzbereich: FM 88...108 MHz, AM 530...1600 kHz. Kopfhöreranschluß über 3,5 mm Klinkenbuchse. Teleskopantenne (40 cm). Ferritantenne (5,5 cm). Einschwenkbare Aufhängevorrichtung an der Rückseite. Alle Funktionen in einem Sony-LIN-IC der Type CXA 1619BM.
Net weight (2.2 lb = 1 kg) 0.170 kg / 0 lb 6 oz (0.374 lb)

Model page created by Peter Roggenhofer † 25.4.18. See "Data change" for further contributors.
