• Year
  • 1965 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 176348

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 6
  • Main principle
  • Superheterodyne (common); 2 AF stage(s)
  • Tuned circuits
  • 4 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Dry Batteries / 4 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.5 inch = 6.4 cm
  • Power out
  • 0.12 W (unknown quality)
  • from Radiomuseum.org
  • Model: Popmaster 141T - Philips Electrical, Lamps,
  • Dimensions (WHD)
  • 5.625 x 3.75 x 1.375 inch / 143 x 95 x 35 mm
  • Notes
  • Chassis similar to model L1G130T.
  • Net weight (2.2 lb = 1 kg)
  • 0 lb 15 oz (0.937 lb) / 0.426 kg
  • Source of data
  • -- Schematic
  • Circuit diagram reference
  • Radio and TV Servicing books (R&TVS) book
  • Author
  • Model page created by Keith Staines. See "Data change" for further contributors.
