Portable Radio 1332 /13 /31 /33
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1975 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 276575
Aus dem Servicemanual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 14
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 10700 kHz
- Tuned circuits
- 8 FM circuit(s)
- Wave bands
- FM Broadcast Band Only
- Power type and voltage
- Line / Batteries (any type) / 220 / 6 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Portable Radio 1332 /13 /31 /33 - Philips; Eindhoven tubes
- Notes
-
Generic model based on service manual. Actual sets may have been distributed under one or more sub brands instead of - or in addition to the Philips brand.
Die hochgeladenen technischen Unterlagen beziehen sich möglicherweise nur auf Philips-Submarken. Es ist nicht sicher, dass es ein Modell mit der genannten Bezeichnung für die eigene Marke Philips gegeben hat.
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
