Radio AM/FM 070 90AL070 /01R

Radio AM/FM 070 90AL070 /01R; Philips Hong Kong (ID = 1954121) Radio Radio AM/FM 070 90AL070 /01R; Philips Hong Kong (ID = 1954122) Radio
Radio AM/FM 070 90AL070 /01R; Philips Hong Kong (ID = 1954123) Radio Radio AM/FM 070 90AL070 /01R; Philips Hong Kong (ID = 1954124) Radio
Radio AM/FM 070 90AL070 /01R; Philips Hong Kong (ID = 1954125) Radio Radio AM/FM 070 90AL070 /01R; Philips Hong Kong (ID = 1954126) Radio
Use red slider bar for more.
Radio AM/FM 070 90AL070 /01R; Philips Hong Kong (ID = 1954121) Radio
Philips Hong Kong: Radio AM/FM 070 90AL070 /01R [Radio] ID = 1954121 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radio AM/FM 070 90AL070 /01R, Philips Hong Kong

Country:  Hong Kong
Manufacturer / Brand:  Philips Hong Kong
Year: 1970 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: ED1502 ED1502 ED1502 ED1502 ED1502 ED1502 ED1502 ED1402 ED1402 ED1702 ED1702
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / AA: 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: Radio AM/FM 070 90AL070 /01R - Philips Hong Kong
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 135 x 75 x 37 mm / 5.3 x 3 x 1.5 inch
Notes

Antenna esterna estensibile ed interna in ferrite.

Presa per cuffia.

Cinghia di trasporto.

Net weight (2.2 lb = 1 kg) 0.3 kg / 0 lb 10.6 oz (0.661 lb)

Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
