Radio Experimente RE2

Radio Experimente RE2; Philips Radios - (ID = 108939) Kit

Radio Experimente RE2; Philips Radios - (ID = 108941) Kit

Radio Experimente RE2; Philips Radios - (ID = 2534035) Kit

Radio Experimente RE2; Philips Radios - (ID = 2534101) Kit

Radio Experimente RE2; Philips Radios - (ID = 2534222) Kit

Radio Experimente RE2; Philips Radios - (ID = 2534223) Kit
Radio Experimente RE2; Philips Radios - (ID = 108911) Kit Radio Experimente RE2; Philips Radios - (ID = 108913) Kit
Radio Experimente RE2; Philips Radios - (ID = 108912) Kit Radio Experimente RE2; Philips Radios - (ID = 108914) Kit
Radio Experimente RE2; Philips Radios - (ID = 108915) Kit Radio Experimente RE2; Philips Radios - (ID = 165542) Kit
Use red slider bar for more.
Radio Experimente RE2; Philips Radios - (ID = 108911) Kit
Philips Radios -: Radio Experimente RE2 [Kit] ID = 108911 933x567
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radio Experimente RE2, Philips Radios - Deutschland

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1964 Category: Kit (Parts plus instruction) or building instructions only
Semiconductors (the count is only for transistors) 3: AF116 AC126 AC126 OA79
Main principle TRF with diode detector; Reflex
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out
from Radiomuseum.org Model: Radio Experimente RE2 - Philips Radios - Deutschland
Material Plastics (no bakelite or catalin)
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 205 x 90 x 98 mm / 8.1 x 3.5 x 3.9 inch
Notes Philips Radio Experimente RE2 enthält alle Bauteile
einschliesslich Gehäuse, die zum Aufbau eines
3-Transistor Mittelwellenempfängers erforderlich sind.
Net weight (2.2 lb = 1 kg) 0.6 kg / 1 lb 5.1 oz (1.322 lb)
Source of data -- Original-techn. papers.

Model page created by Bernhard Nagel. See "Data change" for further contributors.
