Radio Recorder RR50

Radio Recorder RR50; Philips Radios - (ID = 278993) Radio

Radio Recorder RR50; Philips Radios - (ID = 278994) Radio

Radio Recorder RR50; Philips Radios - (ID = 278995) Radio

Radio Recorder RR50; Philips Radios - (ID = 278996) Radio

Radio Recorder RR50; Philips Radios - (ID = 278998) Radio

Radio Recorder RR50; Philips Radios - (ID = 278999) Radio

Radio Recorder RR50; Philips Radios - (ID = 279001) Radio

Radio Recorder RR50; Philips Radios - (ID = 279002) Radio

Radio Recorder RR50; Philips Radios - (ID = 279003) Radio

Radio Recorder RR50; Philips Radios - (ID = 279004) Radio
Radio Recorder RR50; Philips Radios - (ID = 775705) Radio Radio Recorder RR50; Philips Radios - (ID = 775702) Radio
Radio Recorder RR50; Philips Radios - (ID = 775707) Radio Radio Recorder RR50; Philips Radios - (ID = 900010) Radio
Radio Recorder RR50; Philips Radios - (ID = 1779062) Radio Radio Recorder RR50; Philips Radios - (ID = 1779063) Radio
Use red slider bar for more.
Radio Recorder RR50; Philips Radios - (ID = 775705) Radio
Philips Radios -: Radio Recorder RR50 [Radio] ID = 775705 799x581
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radio Recorder RR50, Philips Radios - Deutschland:
Picture from an ended eBay auction, created by franxpost

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1971/1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 21:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 4 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110; 220 / 6×1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 1.2 W (unknown quality)
from Radiomuseum.org Model: Radio Recorder RR50 - Philips Radios - Deutschland
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 340 x 200 x 100 mm / 13.4 x 7.9 x 3.9 inch
Notes Automatische Aussteuerungsregelung für Aufnahme; Löschfrequenz zur Vermeidung von Interferenzstörungen umschaltbar.
Net weight (2.2 lb = 1 kg) 4 kg / 8 lb 13 oz (8.811 lb)
External source of data Erb
Source of data Handbuch VDRG 1971/1972


All listed radios etc. from Philips Radios - Deutschland
Here you find 2510 models, 2237 with images and 1531 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
