Radiophono Portatif H2F52T /00G / 00X

Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064425) Radio

Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064426) Radio

Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064427) Radio

Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064428) Radio

Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064429) Radio

Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064430) Radio

Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064431) Radio

Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064432) Radio

Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064433) Radio

Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064434) Radio
Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064424) Radio
Use red slider bar for more.
Radiophono Portatif H2F52T /00G / 00X; Philips France; (ID = 2064424) Radio
Philips France;: Radiophono Portatif H2F52T /00G / 00X [Radio] ID = 2064424 918x629
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiophono Portatif H2F52T /00G / 00X, Philips France; Paris:
Aus dem Servicemanual

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1966/1967 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: AF121 AF121 AF124 AF124 AF124 BC107 or. BC109 AF127 AC132 AC127 AC128 AC128 AA119 BA114 BA102
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz; 4 AF stage(s)
Tuned circuits 5 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details Record Player (not changer)
Power type and voltage Batteries / addl. power jack / 6 x 1,5 / DC: 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1.3 W (unknown quality)
from Radiomuseum.org Model: Radiophono Portatif H2F52T /00G / 00X - Philips France; Paris
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 310 x 100 x 190 mm / 12.2 x 3.9 x 7.5 inch
Notes

3 gammes d'ondes : GO de 1130 à 2000 m, PO de 184 à 580 m, et FM de 87 à 108 MHz. Cadre ferrite pour AM, antenne télescopique pour FM. HP elliptique inversé type AD2461RY (Z = 4 Ω).

Tourne-disque 3 vitesses, équipé d'une tête de lecture AG3306* ou AG3310.

Exécutions :

  • /00G = coffret gris clair, couvercle gris anthracite
  • /00X = coffret bleu, couvercle gris clair

Les diodes sont mentionnées une fois par type.

* = L'édition 1039-06-66 de la documention mentionne tête AG3306 et T6 BC107.

Mentioned in -- Original-techn. papers.

Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
