• Year
  • 1977 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 207615

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 22
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Recorder F6236 /05 - Philips; Eindhoven tubes
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 420 x 114 x 234 mm / 16.5 x 4.5 x 9.2 inch
  • Net weight (2.2 lb = 1 kg)
  • 4.250 kg / 9 lb 5.8 oz (9.361 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Eduard Abfalterer. See "Data change" for further contributors.
