• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1962–1965

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 24617

• • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors
• AC107 or. OC58 AC107 or. OC58 OC75 OC44 OC75 OC74 OC26 OC79 OA81

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 245 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: RK62 EL3549 - Philips Radios - Deutschland

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 445 x 220 x 385 mm / 17.5 x 8.7 x 15.2 inch

• Notes

• Vierspur; Bandgeschwindigkeiten: 2,4/4,75/9,5/19 cm/s; Spulen-Ø 18 cm.
  Frequenzgang: 50-18000Hz.
  Mit Zusatzverstärker EL3787 Duoplay, Multiplay und Stereo-Wiedergabe möglich; als Mikrofon- und Schalplattenverstärker verwendbar.

• Net weight (2.2 lb = 1 kg)
• 13 kg / 28 lb 10.1 oz (28.634 lb)

• Price in first year of sale
• 699.00 DM

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1962/1963

• Mentioned in
• Handbuch VDRG 1963/1964

• Literature/Schematics (1)
• -- Original-techn. papers.

• Literature/Schematics (2)
• Funk-Technik (FT) (15/1962, S. 506, 507 / Beschreibung, Daten)
