Stella 12RB385
Philips Radios - Deutschland
- Country
- Germany
- Manufacturer / Brand
- Philips Radios - Deutschland
- Year
- 1969–1971
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 27617
-
- Brand: Deutsche Philips-Ges.
Q: Philips, Service-Manaual, 6.69
Q: Philips, Service-Manual, 6.69
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 11
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 5 AM circuit(s) 9 FM circuit(s)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
- Power out
- 3.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Stella 12RB385 - Philips Radios - Deutschland
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 545 x 145 x 175 mm / 21.5 x 5.7 x 6.9 inch
- Notes
- Wellenbereiche: Langwelle, zweimal Mittelwelle, Kurzwelle und UKW (FM).
Gehäuse: Nussbaum oder weiss.
- Net weight (2.2 lb = 1 kg)
- 3 kg / 6 lb 9.7 oz (6.608 lb)
- External source of data
- erb
- Source of data
- Handbuch VDRG 1969/1970
