Stereo Clock Radio D1690 /00 /02
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1986
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 263045
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 2
- Main principle
- Superheterodyne (common); ZF/IF 468/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Batteries / addl. power jack / 3 x 1,5 / 4,5 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 0.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Stereo Clock Radio D1690 /00 /02 - Philips; Eindhoven tubes
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 239 x 100 x 40 mm / 9.4 x 3.9 x 1.6 inch
- Notes
-
Koffergerät für UKW-Stereo-Empfang und MW, Tonschalter, schaltbarer Stereo-Weitwinkel, LED-Stereo-Anzeige, Anschlüsse für 4,5-V- Netzteil und Kopfhörer.
ZF für Ausführung /17 und /47: 455 kHz.
- Mentioned in
- -- Original prospect or advert
- Author
- Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
