Susette L2X21T 9-V-Batt.

Susette L2X21T; Philips; Eindhoven (ID = 448883) Radio Susette L2X21T; Philips; Eindhoven (ID = 1223783) Radio
Susette L2X21T; Philips; Eindhoven (ID = 1223784) Radio Susette L2X21T; Philips; Eindhoven (ID = 1223785) Radio
Susette L2X21T; Philips; Eindhoven (ID = 1223786) Radio Susette L2X21T; Philips; Eindhoven (ID = 1223788) Radio
Susette L2X21T; Philips; Eindhoven (ID = 1223791) Radio
Use red slider bar for more.
Susette L2X21T; Philips; Eindhoven (ID = 448883) Radio
Philips; Eindhoven: Susette L2X21T [Radio] ID = 448883 439x419
Select picture or schematic to display from thumbnails on the right and click for download.
For model Susette L2X21T 9-V-Batt., Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1962–1966 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7:
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
Power out 0.15 W (unknown quality)
from Radiomuseum.org Model: Susette L2X21T [9-V-Batt.] - Philips; Eindhoven tubes
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 170 x 110 x 50 mm / 6.7 x 4.3 x 2 inch
Notes Gemäss Firmencode müsste das Modell Philips Susette L2X21T aus dem Jahre 1962, Fabrikation Holland stammen, kommt aber im deutschen Katalog unter 1965 vor - vielleicht eine Art Ausverkauf.
Net weight (2.2 lb = 1 kg) 0.4 kg / 0 lb 14.1 oz (0.881 lb)
Source of data Handbuch VDRG 1965/1966 / Radiokatalog Band 1, Ernst Erb
