For model TV Couleur Multistandard 26C365 Ch= KM2, Philips; Eindhoven (tubes international!); Miniwatt:
NL Philips type KM2 vue de profil coll. William FAGUE

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1974–1976 Category: Television Receiver (TV) or Monitor
Valves / Tubes 1: A66-140X
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 4 W (undistorted)
from Radiomuseum.org Model: TV Couleur Multistandard 26C365 Ch= KM2 - Philips; Eindhoven tubes
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 741 x 521 x 482 mm / 29.2 x 20.5 x 19 inch
Notes

Téléviseur Couleur 26C365 MultiStandard Pal/Secam.
Tube Cathodique 110° - Ecran 66 cm.
Tout Transistor et Circuit intégré, Equipé de 17 Modules enfichables.
Présélection des Canaux par 12 Boutons "Touch Control" avec indication Lumineuse.
Réglage des Canaux par deux Tiroirs équipés de 6 Potentiomètres et 6 Commutateurs de Bandes chacun.
Réglages par Potentiomètres coulissants.
Préparé pour l'adaptation VCR.

Consommation : 220 watt

Net weight (2.2 lb = 1 kg) 42 kg / 92 lb 8.2 oz (92.511 lb)
Price in first year of sale 6'490.00 FF
Source of data -- Original-techn. papers.
Mentioned in -- Original-techn. papers. (Philips Model Number Survey 2003)

Model page created by Patrice Schoser. See "Data change" for further contributors.
